Zed & Cee Purlins and Girts

Lightweight structural steel members

Zed & Cee Purlins and Girts

Lightweight structural steel members

Description

Zed and Cee Purlins and Girts are lightweight structural steel members, designed in accordance with the AS/NZS 4600: 1996 Cold Formed Steel Structures utilising high strength zinc-coated steel.
Zed sections may be used over single spans, unlapped and lapped continuous spans in multi-bay buildings. Lapped continuous spans result in considerable capacity increase in the system.
Cee sections may be used in single spans, and unlapped continuous spans in multi-bay building and are ideal as eave purlins or where compact sections are required for detailing.

  • A range of gauges and depths are available
  • Can be provided punched and unpunched
  • Non-standard sizes may be available on application
  • A down-turned bottom lip on your Zed Purlin, is available on request

Specifications



Zed and Cee sections are roll-formed from Zinc-coated steel complying with AS1397 – 1993. In the grades shown, the numbers prefixed with G indicate minimum yield stress in MPa. The numbers prefixed with Z indicate minimum coating mass in g/m2.

1.0mm BMT: G550, Z350*
1.2mm BMT: G500, Z350*
1.5, 1.9, 2.4 & 3.0 mm BMT: G450, Z350



Section Properties

Section properties for different purlin configurations can be found in the downloadable manual



Schematics









Downloads
